Running Type Electric Chain Hoist with 50T Capacity and Customizable Lifting Height in Light Aluminum Alloy Shell

Running Type Electric Chain Hoist with 50T Capacity and Customizable Lifting Height in Light Aluminum Alloy Shell
Running Type Electric Chain Hoist with 50T Capacity and Customizable Lifting Height in Light Aluminum Alloy Shell
video play

Large Image :  Running Type Electric Chain Hoist with 50T Capacity and Customizable Lifting Height in Light Aluminum Alloy Shell

Product Details:
Place of Origin: CHINA
Brand Name: JCYC/OEM
Certification: CE ISO9001 manufacturing licence
Model Number: SY-A
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: $300-$10000
Packaging Details: Plywood Case
Delivery Time: 20-30 working day
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 1000pcs per month
Contact Now
Detailed Product Description
Product Name: Electric Chain Hoist With Electric Trolley Capacity: 0.3 Ton To 50 Ton
Lifting Height: 3/6/9/12/18m Or At Request Power Supply: 220V-690V 3Phase 50/60Hz
Color: Yellow/orange Or At Request Model: Fixed Type &running Type
Highlight:

G80 Load Electric Chain Hoist

,

50T Material Lifting Electric Chain Hoist

,

12m Lifting Electric Chain Hoist

Running Type G80 Load Electric Chain Hoist 50T Material Lifting
Electric G80 Load Chain Trolley 1t Chain Hoist Material Lifting High Strength
Brief Introduction
Electric chain hoists are durable, compact, and quiet, operating smoothly to lift and move heavy loads. They are easy to handle and service, reducing labor costs and power consumption while improving efficiency in material handling applications. Our selection includes single-phase chain hoists for smaller operations, spark-resistant and stainless steel options for cleanroom environments, and three-phase chain hoists for large capacity requirements.
Running Type Electric Chain Hoist with 50T Capacity and Customizable Lifting Height in Light Aluminum Alloy Shell 0
Structure Features
The body features a high-strength tensile shell or die-cast aluminum case with thin-walled precision manufacturing for compact size, light weight, and high strength. The separate speed-adjusting system includes a sealed 2-coaxial transmission speed gear mechanism with long-service oil bath lubrication.
The electric hoist uses a powder metallurgy clutch for overload protection and a DC magnetic field brake disc for stable, rapid braking with minimal noise. Custom capacity, lifting height, and types are available upon request.
Running Type Electric Chain Hoist with 50T Capacity and Customizable Lifting Height in Light Aluminum Alloy Shell 1
  1. Shell: Light aluminum alloy with cooling fins for 40% faster heat dissipation, suitable for chemical plants and electroplating factories.
  2. Support Frame: Two steel plates for extreme sturdiness.
  3. Side Magnetic Braking Device: Latest design for instant braking when power is cut off, ensuring loading safety.
  4. Transformer: 24V/36V/48V/10V device prevents accidents from electric leakage and ensures safe use in rain.
  5. Limit Switch: Automatically stops motor to prevent chain overextension.
  6. Chain: Imported FEC G80 ultra heat-treatable aluminum alloy chain resistant to rain, seawater, and chemicals.
  7. Hook: Hot-forged for perfect strength with 360° rotation and safety flap.
  8. Electromagnetic Contactor: Safe operation under high frequency.
  9. Inverse Phase Sequence Protecting Device: Prevents circuit operation in case of wiring errors.
  10. Control Switch: Waterproof push button that's light and durable.
Product Technical Parameters
Model Lifting Capacity (t) Lifting Height (m) Lifting Speed (m/min) Running Speed (m/min) Lifting Motor Power (kw) Power Supply Running Motor Power (kw) I-Beam (mm)
SY-A0.5-10.53-96.812.20.75220-440V 50/60HZ 3Phase0.1258-130
SY-A1-113-96.610/201.5220-440V 50/60HZ 3Phase0.480-160
SY-A1-213-93.410/200.75220-440V 50/60HZ 3Phase0.480-160
SY-A2-123-96.610/203.0220-440V 50/60HZ 3Phase0.482-178
SY-A2-223-93.310/201.5220-440V 50/60HZ 3Phase0.482-178
SY-A3-133-95.410/203.0220-440V 50/60HZ 3Phase0.4100-180
SY-A3-233-94.411/213.0220-440V 50/60HZ 3Phase0.4100-178
SY-A3-333-92.411/211.5220-440V 50/60HZ 3Phase0.4110-178
SY-A5-253-92.710/203.0220-440V 50/60HZ 3Phase0.75110-180
SY-A7.5-37.53-91.810/203*2220-440V 50/60HZ 3Phase0.75120-180
SY-A10-4103-92.710/203*2220-440V 50/60HZ 3Phase0.75150-202
SY-A15-6153-91.910/203*2220-440V 50/60HZ 3Phase0.75*2150-220
SY-A20-8203-91.410/203*2220-440V 50/60HZ 3Phase0.75*2150-220
SY-A25-8253-91.110/203*2220-440V 50/60HZ 3Phase0.75*2150-220
SY-A30-10303-90.910/203*2220-440V 50/60HZ 3Phase0.75*2150-220
SY-A35-16353-90.710/203*2220-440V 50/60HZ 3Phase0.75*2150-220
Factory Show
Running Type Electric Chain Hoist with 50T Capacity and Customizable Lifting Height in Light Aluminum Alloy Shell 2 Running Type Electric Chain Hoist with 50T Capacity and Customizable Lifting Height in Light Aluminum Alloy Shell 3
