3t Capacity Electric Chain Hoist with Light Aluminum Alloy Shell and Magnetic Braking Device for Customizable Lifting Height

Products

3t Capacity Electric Chain Hoist with Light Aluminum Alloy Shell and Magnetic Braking Device for Customizable Lifting Height

MOQ:	1 piece
Price:	$300-$10000
Standard Packaging:	Plywood Case
Delivery Period:	20-30 working day
Payment Method:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Capacity:	1000pcs per month

Detail Information

Product Description

Detail Information

Place of Origin

CHINA

Brand Name

JCYC/OEM

Certification

CE ISO9001 manufacturing licence

Model Number

Product Name:

380V 220V 5tons 3tons Electric Chain Hoist With Electric Trolley Price

Capacity:

0.3 Ton To 50 Ton

Lifting Height:

3/6/9/12/18m Or At Request

Power Supply:

220V-690V 3Phase 50/60Hz

Color:

Yellow/orange Or At Request

Highlight:

Electric Trolley 3t Chain Hoist

Material Lifting 3t Chain Hoist

High Strength 3t Chain Hoist

Product Description

Electric Trolley 3t Chain Hoist Material Lifting High Strength

Our 380V/220V electric chain hoists with trolley are available in capacities from 0.5 to 35 tons, offering durable, compact, and quiet operation for smooth lifting and moving of heavy loads. These hoists are designed for easy handling and maintenance, reducing labor costs while minimizing power consumption and operation time.

We provide a comprehensive selection including single-phase models for smaller operations, spark-resistant and stainless steel options for cleanroom environments, and three-phase hoists for heavy-duty applications. Custom configurations are available to meet specific lifting requirements.

Structure Features

The hoist features a high-strength tensile shell or die-cast aluminum case with precision thin-wall manufacturing for compact size, light weight, and exceptional durability. The separate speed-adjusting system incorporates a sealed coaxial transmission gear mechanism with oil bath lubrication for long service life.

Safety features include a powder metallurgy clutch for overload protection and DC magnetic field brake discs for stable, rapid braking with minimal noise. Custom capacity, lifting height, and configuration options are available upon request.

Key Components

Shell: Lightweight aluminum alloy construction with optimized cooling fins for 40% faster heat dissipation, suitable for harsh environments like chemical plants.
Support Frame: Dual steel plate construction for maximum sturdiness and load-bearing capacity.
Side Magnetic Braking: Advanced magnetic force generator enables instant braking when power is interrupted for enhanced safety.
Transformer: 24V/36V/48V/10V transformer prevents accidents from electric leakage, ensuring safe operation in wet conditions.
Limit Switch: Automatic motor cutoff prevents chain overrun for operator safety.
Chain: Imported FEC G80 heat-treated aluminum alloy chain resistant to rain, seawater, and chemicals.
Hook: Hot-forged construction with 360° rotation and safety flap for secure load handling.
Electromagnetic Contactor: Reliable performance under high-frequency operation.
Phase Protection: Prevents circuit operation during power supply wiring errors.
Control Switch: Waterproof push button design for durability in demanding environments.

Technical Specifications

Model	Capacity (t)	Lift Height (m)	Lift Speed (m/min)	Run Speed (m/min)	Lift Motor Power (kw)	Lift Motor RPM	Power Supply	Run Motor Power (kw)	Run Motor RPM	I-Beam (mm)
SY-A0.5-1	0.5	3-9	6.8	12.2	0.75	1440	220-440V 50/60HZ 3Phase	0.12	1440	58-130
SY-A1-1	1	3-9	6.6	10/20	1.5	1440	220-440V 50/60HZ 3Phase	0.4	1440	80-160
SY-A1-2	1	3-9	3.4	10/20	0.75	1440	220-440V 50/60HZ 3Phase	0.4	1440	80-160
SY-A2-1	2	3-9	6.6	10/20	3.0	1440	220-440V 50/60HZ 3Phase	0.4	1440	82-178
SY-A2-2	2	3-9	3.3	10/20	1.5	1440	220-440V 50/60HZ 3Phase	0.4	1440	82-178
SY-A3-1	3	3-9	5.4	10/20	3.0	1440	220-440V 50/60HZ 3Phase	0.4	1440	100-180
SY-A3-2	3	3-9	4.4	11/21	3.0	1440	220-440V 50/60HZ 3Phase	0.4	1440	100-178
SY-A3-3	3	3-9	2.4	11/21	1.5	1440	220-440V 50/60HZ 3Phase	0.4	1440	110-178
SY-A5-2	5	3-9	2.7	10/20	3.0	1440	220-440V 50/60HZ 3Phase	0.75	1440	110-180
SY-A7.5-3	7.5	3-9	1.8	10/20	3*2	1440	220-440V 50/60HZ 3Phase	0.75	1440	120-180
SY-A10-4	10	3-9	2.7	10/20	3*2	1440	220-440V 50/60HZ 3Phase	0.75	1440	150-202
SY-A15-6	15	3-9	1.9	10/20	3*2	1440	220-440V 50/60HZ 3Phase	0.75*2	1440	150-220
SY-A20-8	20	3-9	1.4	10/20	3*2	1440	220-440V 50/60HZ 3Phase	0.75*2	1440	150-220
SY-A25-8	25	3-9	1.1	10/20	3*2	1440	220-440V 50/60HZ 3Phase	0.75*2	1440	150-220
SY-A30-10	30	3-9	0.9	10/20	3*2	1440	220-440V 50/60HZ 3Phase	0.75*2	1440	150-220
SY-A35-16	35	3-9	0.7	10/20	3*2	1440	220-440V 50/60HZ 3Phase	0.75*2	1440	150-220

Factory Overview
