| Product Name: | Electric Trolley | Motor: | 0.12 To 0.75kw |
|---|---|---|---|
| Capacity: | 0.5t-5t | Speed: | 11/21 M/min |
| Application: | Electric Chain Hoist | Color: | Orange |
| High Light: | stainless steel chain hoist,high speed chain hoist |
||
0.5t 1t 2t 3t 5t Electric Chain Hoist / Crane Trolley , High Speed Chain Hoist Yellow Color
Features:
SY series electric trolley is one of our perfect products. The unique side guide system makes our trolley drivers smoothly. Frequency control of motor speed is available, which is able to match various working situation and environment.
Characteristics:
Simple structure gear box.
Light self weight motor and well balanced.
| Model | Capacity (T) |
Unit(mm) | Speed 50HZ (m/min) |
Motor(kw) | Minimum radius of turn |
I-Beam | |||
| A | B | R | T | ||||||
| SY-ET-0.5 | 0.5 | 198 | 248 | 142 | 159 | 12.2 | 0.12 | 0.8 | 52-153 |
| SY-ET-01 | 1 | 315 | 212 | 142 | 231 | 11-21 | 0.4 | 0.8 | 52-153 |
| SY-ET-02 | 2 | 325 | 220 | 142 | 231 | 11-21 | 0.4 | 0.8 | 82-178 |
| SY-ET-03 | 3 | 340 | 250 | 142 | 231 | 11-21 | 0.4 | 1 | 100-178 |
| SY-ET-05 | 5 | 400 | 291 | 142 | 231 | 11-21 | 0.75 | 1.8 | 100-178 |
| SY-ET-7.5 | 7.5 | 400 | 291 | 142 | 231 | 11-21 | 0.75 | 1.8 | 100-178 |
| SY-ET-10 | 10 | 500 | 370 | 142 | 231 | 11-21 | 0.75 | 2.5 | 150-220 |
