5 ton capacity 380V power supply electric winch with 15m/min slow speed for marine and construction use

Products

5 ton capacity 380V power supply electric winch with 15m/min slow speed for marine and construction use

MOQ:	1 pc
Price:	Negotiable
Standard Packaging:	Carton
Delivery Period:	15 working days
Payment Method:	L/C,T/T,Western Union
Supply Capacity:	500 pcs/month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

JCYC

Certification

Model Number

Product:

5 Ton Electric Winch

Max. Cap:

30 Ton

Min. Cap:

1 Ton

Lifting System:

Electric Motor

Product Type:

Wire Rope

Control Type:

Electrical Box

Application:

Australia Construction Industry

Rope Length:

100M-500M

Oem Service:

Available

Model:

Usage:

Cable Pulling Machine, Carry Heavy Goods

Highlight:

horizontal plate clamp

steel lifting clamps

Product Description

5 Ton Electric Winch 380V Slow Speed 15m/min Rope Winch for Marine Use

JM 5 Ton Electric Winch

The electric winch is primarily designed for hoisting, pulling, and loading or unloading heavy materials. It is suitable for mounting and dismounting large and medium-sized concrete and steel structures, as well as machinery equipment. Additionally, it can serve as the lifting mechanism for various hoisting machinery applications.

Product Features

Orderly-arranged steel wire ropes for safe operation
Smooth transmission system
Convenient maintenance access
Ideal for bridge building, port construction, shipyard operations, and large-scale industrial projects
Custom design options available for specific requirements

Standard Configurations

Electric Motor: IP44-protected for general engineering applications
Steel Rope: Available in wire rope or synthetic rope with customizable length and diameter
Drum: Cylindrical design for efficient rope storage and winding operations
Transmission System: Options include worm gearbox, spur gearbox, and planetary gearbox
Brake System: Available with motor brake, transmission brake, or drum brake
Control System: Standard control box with up/down push buttons and emergency stop; remote control available

JM Slow-Speed Electric Winch Specifications

The slow-speed winch operates at speeds ranging from 5m/min to 20m/min, providing precise load control and accurate positioning. With marine duty design, it is suitable for both boat and shore applications including anchoring, mooring, and towing operations.

General Specifications:
Loading capacity: 0.5~200 t
Rope capacity: 10~2000 m
Working speed: 5~20 m/min (single speed or dual speed)
Power supply: 220-690V, 50/60HZ, 3Phase

Model	Cable Rated Pull (kg)	Cable Rated Speed (m/min)	Wire Rope (Φmm)	Wire Rope Length (m)	Drum (mm) Dia(Φ)	Motor Power (kw)
JM0.5	500	15	Φ7.7	50/120	Φ140*300	2.2
JM1	1000	15	Φ9.3	70/120	Φ165*415	5.5
JM1.5	1500	15	Φ12.5	80/180	Φ219*450	7.5
JM2	2000	15	Φ12.5	80/180	Φ219*480	7.5
JM3	3000	15	Φ15.5	100/200	Φ219*525	11
JM5	5000	9	Φ19.5	250	Φ325*620	11
JM8	8000	9	Φ26	300	Φ406*808	15
JM10	10000	9	Φ30	350	Φ406*900	22
JM16	16000	9	Φ38	400	Φ550*1000	37
JM20	20000	9	Φ42	450	Φ650*1300	45
JM30	30000	9	Φ54	450	Φ900*1500	63

Quotation Requirements

To provide an accurate quotation, please provide the following information:

Purpose of the winch: lifting or pulling?
Intended use location: construction, mine, or marine?
Required capacity
Rope volume requirements
Required rope speed
Voltage specifications
Any additional requests such as dual speed or extra equipment

Note: The more detailed information provided, the more accurate the quotation will be.
