European Type Electric Wire Rope Hoist Double Girder Double Speed M5

MOQ: 1 pcs
Price: Negotiable
Standard Packaging: plywood case
Delivery Period: 10 -15 working days
Payment Method: L/C,T/T,Western Union,D/A,D/P,MoneyGram
Supply Capacity: 500 units per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
JCYC
Certification
CE&ISO
Model Number
SHSL
Name:
European Type Electric Wire Rope Hoist Double Girder Double Speed M5
Capacity:
1t To 100t
Standard Lifting Height:
6/9/12/18M
Power Source:
380V 3P 50Hz
Working Duty:
M4 M5
Warranty:
1/3 Years
Incoterm:
FOB; CFR; EXW
Port:
Shanghai
Highlight:

Double Girder Wire Rope Hoist

,

Double Speed electric wire rope winch

,

adaptable wire rope hoist

Product Description

European Type Electric Wire Rope Hoist Double Girder Double Speed M5

Product Introduction

European Type Electric Wire Rope Hoist

It is a up to date developed product by combining and applying the advanced German technologies. It has compact structure and its frame is in rectangular shape. Its drum is made of seamless steel pipe. Its planetary gearbox, which is in the hoisting drum, electromotor and electric control box is in beeline collocation. The hoist has overload protection , overheating protection and phase relay protection devices. Its modular design can realize the seamless connection with frequency inverter, automatic weighing system and automatic detection system.

Application

It is widely used for overhead crane, gantry crane etc. heavy duty industry, light duty industry especially highly resticted environment plants.

Features

  • Easy and adaptable wire rope hoist
  • Rugged and compact
  • Modular construction and easy maintenance
  • Light weight
  • Small volumn
  • Clearance height minimum

Configuration

Capacity
(t)		 Lifting Height
(m)		 Lifting Speed
(m/min)		 Lifting Motor
(kw)		 Travelling Speed
(m/min)

Travel

Motor
(kw)

Lifting/

Travel System
(FEM)

 I-Beam Width
(mm)
3.2 6/9/12/15/18 5/0.8 3.2/0.45 5/20 0.37 M5 150-300
5 6/9/12/15/18 5/0.8 6.1/1 5/20 0.37 M5 200-350
6.3 6/9/12/15/18 5/0.8 6.1/1 5/20 0.37 M4 200-350
10 6/9/12/15/18 5/0.8 9.5/1.5 5/20 0.75 M5 200-410
16 6/9/12/15/18 4/0.6 16/2.6 5/20 0.75*2 M5 300-450
20 6/9/12/15/18 4/0.6 16/2.6 5/20 0.75*2 M4 300-450

Product show

European Type Electric Wire Rope Hoist Double Girder Double Speed M5 0

European Type Electric Wire Rope Hoist Double Girder Double Speed M5 1

European Type Electric Wire Rope Hoist Double Girder Double Speed M5 2

European Type Electric Wire Rope Hoist Double Girder Double Speed M5 3

European Type Electric Wire Rope Hoist Double Girder Double Speed M5 4

A customer use case

European Type Electric Wire Rope Hoist Double Girder Double Speed M5 5

Exhibition

European Type Electric Wire Rope Hoist Double Girder Double Speed M5 6

Contact me

European Type Electric Wire Rope Hoist Double Girder Double Speed M5 7
