Capacity 10t 6m Lifting G80 Load Electric Chain Hoist For Warehouses Garages

China Chongqing Shanyan Crane Machinery Co., Ltd. certification
China Chongqing Shanyan Crane Machinery Co., Ltd. certification
Nice quality

—— George

Professional and delivery on time, treat me good.

—— Patrick

Works perfectly !

—— Khalid

Thanks for your good after-sale service. Excellent training and technology support helps me a lot.

—— Kent Rosal

Please develop more nice hoist and with better prices, so we can sell your hoist to more clients and gain larger markets. Thank you.

—— Khalid Abu Hasera

Mr. Sen is a nice man, he help me a lot, thanks for you give us quickly respone and save us many times. good job!

—— Sivakumar veerappa nainar

I'm Online Chat Now

Capacity 10t 6m Lifting G80 Load Electric Chain Hoist For Warehouses Garages

Capacity 10t 6m Lifting G80 Load Electric Chain Hoist For Warehouses Garages
Capacity 10t 6m Lifting G80 Load Electric Chain Hoist For Warehouses Garages
video play

Large Image :  Capacity 10t 6m Lifting G80 Load Electric Chain Hoist For Warehouses Garages

Product Details:
Place of Origin: CHINA
Brand Name: JCYC/OEM
Certification: CE ISO9001 manufacturing licence
Model Number: SY-A
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: Plywood Case
Delivery Time: 20-30 working day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000pcs per month
Detailed Product Description
Product Name: Electric Chain Hoist Capacity: 0.3 Ton To 50 Ton
Lifting Height: 3/6/9/12/18m Or At Request Power Supply: 220V-440V 3Phase 50/60Hz
Color: As Per Request OEM: Yes
High Light:

6m Lifting Electric Chain Hoist

,

G80 Load Electric Chain Hoist

,

10t Garages Electric Chain Hoist

Capacity 10t 6m Lifting G80 Load Chain Hoist For Warehouses Garages





Brief Introduction:



Electric chain hoist has a small,compact,light weight and cool design,use single/triple phase power supply,quickly and easily operates,easy to install,security,reliability and widely using. Ideal lifting tools for DIY, warehouses, garages, farms, hunting, engine repair shops, machine shops, restaurants, AD boards hold, show and home improvement etc, also perfect for loading and unloading heavy items from trucks and trailers.







Structure Features



The body chooses to use high strength tensile shell or die casting aluminum case, extrusion molding process thin-walled precision manufacturing, small size, low weight, high strength.
Seperate speed-adjusting system, seal the level 2 coaxial transmission speed gear mechanism with long-service oil bath lubrication system.
The electric hoist powder metallurgy clutch is used for overload protection device. The brake disc adopts dc magnetic field, braking torque, stable and rapid, the noise is small.

1. Hooks

Drop forged steel suspension & load hooks are heat treated and fracture resistant. In case of dangerous overloading or abuse, the hook does not fracture but will slowly yield.


2. Power
Operating voltage 220-440V, 50/60Hz, 1-3 phase.
Low voltage control 36V is standard.


3. Motor
High efficient energy-saving motor, asbestos free brake system. 2-speed motor available.


4. Chain
Alloy steel chain super strong surface hardened for optimum strength and wear resistance.


5. Chain Bucket
Solid chain bucket as standard part for safer operation


6. Limit Switch
Limit switch devices fitted at both top & bottom ends, switch off power automatically to prevent load chain from running out.


7. Phase Error Relay
Phase error relay, a specially designed current-post, prevents motor from running at incorrect wire connection.


8. Pushbutton Swith
Pushbutton swith is rain-proof plastic for severe impact and corrosive atmosphere resistance and mechanically interlocked.


9. Safety Latches
Top and bottom hooks are fitted with safety latches as standard.

10. Light Wight
Light weight, compact and solid body case.


11. Push Button Control
Fits operator's hand operation. Impact and chemical atmosphere resistant.


Product technical parameters:



Model Lifting Capacity(t) Lifting Height(m) Lifting Speed(m/min) Running Speed(m/min) Lifting Motor Running Motor I-Beam(mm)
Power(kw) R.P.M(r/min) Power Supply Power(kw) R.P.M(r/min) Power Supply
SY-A0.5-1 0.5 3-9 6.8 12.2 0.75 1440 220-440V 50/60HZ 3Phase 0.12 1440 220-440V 50/60HZ 3Phase 58-130
SY-A1-1 1 3-9 6.6 10/20 1.5 1440 0.4 1440 80-160
SY-A1-2 1 3-9 3.4 10/20 0.75 1440 0.4 1440 80-160
SY-A2-1 2 3-9 6.6 10/20 3.0 1440 0.4 1440 82-178
SY-A2-2 2 3-9 3.3 10/20 1.5 1440 0.4 1440 82-178
SY-A3-1 3 3-9 5.4 10/20 3.0 1440 0.4 1440 100-180
SY-A3-2 3 3-9 4.4 11/21 3.0 1440 0.4 1440 100-178
SY-A3-3 3 3-9 2.4 11/21 1.5 1440 0.4 1440 110-178
SY-A5-2 5 3-9 2.7 10/20 3.0 1440 0.75 1440 110-180
SY-A7.5-3 7.5 3-9 1.8 10/20 3*2 1440 0.75 1440 120-180
SY-A10-4 10 3-9 2.7 10/20 3*2 1440 0.75 1440 150-202
SY-A15-6 15 3-9 1.9 10/20 3*2 1440 0.75*2 1440 150-220
SY-A20-8 20 3-9 1.4 10/20 3*2 1440 0.75*2 1440 150-220
SY-A25-8 25 3-9 1.1 10/20 3*2 1440 0.75*2 1440 150-220
SY-A30-10 30 3-9 0.9 10/20 3*2 1440 0.75*2 1440 150-220
SY-A35-16 35 3-9 0.7 10/20 3*2 1440 0.75*2 1440 150-220





Capacity 10t 6m Lifting G80 Load Electric Chain Hoist For Warehouses Garages 0



Factory show:



Capacity 10t 6m Lifting G80 Load Electric Chain Hoist For Warehouses Garages 1

Capacity 10t 6m Lifting G80 Load Electric Chain Hoist For Warehouses Garages 2





Capacity 10t 6m Lifting G80 Load Electric Chain Hoist For Warehouses Garages 3Capacity 10t 6m Lifting G80 Load Electric Chain Hoist For Warehouses Garages 4
