380V 220V Lift Speed 8m/Min Electric Wire Rope Hoist
  • name
  • name
  • name

380V 220V Lift Speed 8m/Min Electric Wire Rope Hoist

MOQ: 1 set
Price: Negotiable
Standard Packaging: Plywood case
Delivery Period: 15 to 30 working days
Payment Method: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity: 300 sets per month
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
JCYC
Certification
CE/ISO
Model Number
CD1 /MD1
Product Name:
CD1 Model Electric Wire Rope Hoist
Capacity:
1T - 30T
Lifting Height:
6/9/12/24m
Color:
As Per Request
Lift Speed:
8m/min (as Customised)
Voltage:
380V /50Hz
Highlight:

electric lifting hoist

,

stainless steel wire rope hoist

Product Description

CD1 Single Girder Type Wire Rope Electric Hoist Customized Popular Model 380V/220V



Product Description



Product Application



The CD and MD type wire rope electric hoist is a kind of light and small lifting equipment, which can be installed on single beam crane, bridge crane, gantry crane, arm cranes, cantilever cranes, etc. It can also be used as a winch. It is widely used in factories, mines, harbors, warehouses, cargo storage areas and shops. CD has one speed, MD has two speed.



Our factory can produce 1-50 tons of wire rope electric winch hoist, including CD and MD type, low headroom hoist, explosion proof electric hoist, European type electric hoist and chain hoist. The hoist can be with pendent control and wireless remote control. Totally can be customised strictly according to your specific requirement.



Product Technical parameters



380V 220V Lift Speed 8m/Min Electric Wire Rope Hoist 0



Model Lifting Capacity (t) Lifting Height (m) Lifting Speed (m/min) Running Speed (m/min) Wire Rope Type Dia.of Wire Rope (mm) I Beam Track Type Working Duty Lifting Motor Running Motor
Power(kw) R.P.M ( r/min) Power Supply Power(kw) R.P.M ( r/min) Power Supply
CD1-0.25 0.25 3-9 8 20 6*19 3.6 16-22b M3 0.4 1380 220-440V 50/60HZ 3Phase 0.06 1400 220-440V 50/60HZ 3Phase
CD1-0.5 0.5 6-12 8 20 6*37+1 4.8 16-28b M3 0.8 1380 0.2 1380
CD1-1 1 6-30 8 20 6*37+1 7.4 16-28b M3 1.5 1380 0.2 1380
CD1-2 2 6-30 8 20 6*37+1 11 20a-32c M3 3 1380 0.4 1380
CD1-3 3 6-30 8 20 6*37+1 13 20a-32c M3 4.5 1380 0.4 1380
CD1-5 5 6-30 8 20 6*37+1 15 25a-63c M3 7.5 1380 0.8 1380
CD1-10 10 6-30 7 20 6*37+1 15 25a-63c M3 13 1400 0.8*2 1380
CD1-16 16 6-30 3.5 20 6*37+1 15 45a-63c M2 13 1400 0.8*2 1380
CD1-20 20 6-30 3.5 20 6*37+1 20 50a-63c M2 13 1400 0.8*2 1380
