Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane

Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane
Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane

Large Image :  Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane

Product Details:
Place of Origin: China
Brand Name: JCYC
Certification: CE & ISO9001
Model Number: GL
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Plywood case
Delivery Time: 15 to 20 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 to 300 sets per week
Detailed Product Description
Product Name: Crane End Carriage Motor Traveling End Truck Carriage For Single / Double Girder Crane Power Source: 3 Phase 380V 50hz
Crane Feature: Single Girder Oveherd Crane Lifting Mechanism: Electric Trolley
Control Method: Wireless Remote Control Rated Loading Capacity: 1~20t
Span: As You Request
High Light:

end carriage overhead crane

,

end carriage of crane

Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane


Product Brief Introduction:



The JCYC brand end carriages is an important component installed at both ends of the main beam of the overhead crane to support the bridge in the sky.
The end carriage includes two parts, a wheel and an end beam frame. The end beam frame is composed of an upper cover plate, a web plate, and a lower cover plate. The connection plate and the angle steel are fastened with bolts.





Product Installation:



1. Connecting Plate Installation

Put the connection plate on the top of end carriage, Align the

Positioning Pin Hole and put the flexible positioning pins of onto

the holeφ10x30 into the hole to fix the connection plate.Connect

the connection plate and end carriage with bolt M16x70.

Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane 0



2. Wheel Installation

Press the two bearings into the two sides of wheels and then

put it into the end carriage; Fix the wheels with shaft and shaft sleeve.

Fix the shaft with the shaft platen; Fix the shaft platen with Bolts.

Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane 1





3. Seal Plate and Rubber buffer installation

Install the Rubber buffer onto seal plate and then fixed the seal plate onto the two ends of the end carriage with bolts.

Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane 2



4. Current Collector Mounting Plate Installation

This mounting plate is used for Current Collector Bracket installation at site.Remove the mounting plate when install the Current Collector Bracket, Welding the bracket onto the mounting plate and then fix the mounting plate onto the End carriage with Bolts.

Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane 3




Product Technical Parameters:



Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane 4



Model Crane Rectangular
Steel tube
Wheel Size Motor power S1
(mm)
S2
(mm)
W1
(mm)
W2
(mm)
GL125-15 1t-7.5m 150*150*6 W125*60 0.3KW*2 1500 1300 400 500
GL125-20 1t-11.5m 2000 1800 400 500
GL125-25 1t-16.5m 2500 2300 400 500
GL160-15 2t/3t-7.5m 150*200*8 W160*70 0.4KW*2 1500 1200 400 500
GL160-20 2t/3t-11.5m 2000 1700 400 500
GL160-25 2t/3t-16.5m 2500 2200 400 500
GL160-30 2t/3t-22.5m 3000 2700 500 600
GL160-35 2t/3t-28.5m 3500 3200 600 700
GL200-20 5t-11.5m 150*250*8 W200*70 0.4KW*2 2000 1700 400 500
GL200-25 5t-16.5m 2500 2200 400 500
GL200-30 5t-22.5m 0.75KW*2 3000 2700 500 600
GL200-35 5t-28.5m 3500 3200 600 700
GL250-20 10t-11.5m 200*250*8 W250*80 0.75KW*2 2000 1600 400 500
GL250-25A 10t-16.5m 2500 2100 500 600
GL250-30A 10t-22.5m 1.1KW*2 3000 2600 500 600
GL250-35A 10t-28.5m 3500 3100 700 800
GL250-25B 16t-16.5m 200*300*8 W250*80 1.1KW*2 2500 2100 600 700
GL250-30B 16t-22.5m 3000 2600 700 800
GL250-35B 16t-28.5m 1.5KW*2 3500 3100 700 800
GL315-30 20t-16.5m 200*400*8 W315*90 1.5KW*2 3000 2500 700 800
GL315-35 20t-22.5m 3500 3000 700 800



Product show:



Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane 5

Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane 6

Crane End Carriage Motor Traveling End Truck Carriage for Single / Double Girder Crane 7
