Wire Rope Double Girder M4 M5 Foot Mounted Hoist
  • name
  • name
  • name

Wire Rope Double Girder M4 M5 Foot Mounted Hoist

MOQ: 1 pcs
Price: USD negotiate per unit
Standard Packaging: Plywood case
Delivery Period: 10 -15 working days
Payment Method: L/C, T/T, Western Union
Supply Capacity: 500 pcs per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
JCYC
Certification
CE&ISO
Model Number
CD
Capcity:
1T-20T
Lifting Height:
6m-30m
Working Group:
M4/M5
Travelling Speed:
20/6.7m/min
Lifting Motor:
3/4.5/7.5/13kw
Color:
As Per Request
Highlight:

electric lifting hoist

,

stainless steel wire rope hoist

Product Description

Electric Wire Rope Double Girder Foot Mounted Hoist





Widely used in factories, mines, harbours, warehouses, cargo storage areas and shops, essential in raising working efficiency and improving working conditions.





Product Details:



Foot-mounted Electric Wire Rope Hoist (2/1 Rope Reeving)



Features and advantages:



1. Particularly favorable hook paths.

2. Anti derailment and lift-off protection design.

3. Makes optimum use of headroom.

4. Excellent approach dimensions thanks to compact design.

5. The main parts of it adopt high quality material to ensure durability.

6. Special specifications and marks can be made according to customers' requirements.



Model Lifting Capacity (t) Lifting Height (m) Lifting Speed (m/min) Running Speed (m/min) Wire Rope Type Dia.of Wire Rope (mm) I Beam Track Type Working Duty Lifting Motor Running Motor
Power(kw) R.P.M ( r/min) Power Supply Power(kw) R.P.M ( r/min) Power Supply
CD1-0.25 0.25 3-9 8 20 6*19 3.6 16-22b M3 0.4 1380 220-440V 50/60HZ 3Phase 0.06 1400 220-440V 50/60HZ 3Phase
CD1-0.5 0.5 6-12 8 20 6*37+1 4.8 16-28b M3 0.8 1380 0.2 1380
CD1-1 1 6-30 8 20 6*37+1 7.4 16-28b M3 1.5 1380 0.2 1380
CD1-2 2 6-30 8 20 6*37+1 11 20a-32c M3 3 1380 0.4 1380
CD1-3 3 6-30 8 20 6*37+1 13 20a-32c M3 4.5 1380 0.4 1380
CD1-5 5 6-30 8 20 6*37+1 15 25a-63c M3 7.5 1380 0.8 1380
CD1-10 10 6-30 7 20 6*37+1 15 25a-63c M3 13 1400 0.8*2 1380
CD1-16 16 6-30 3.5 20 6*37+1 15 45a-63c M2 13 1400 0.8*2 1380
CD1-20 20 6-30 3.5 20 6*37+1 20 50a-63c M2 13 1400 0.8*2 1380





T
Tags:

electric lifting hoist,

stainless steel wire rope hoist,

wire rope crane hoist
