1 Ton Electric Chain Hoists for stage With double brake Entertainment

MOQ: 2 pcs
Price: Negotiable
Standard Packaging: plywood
Delivery Period: 3 working days
Payment Method: T/T,Western Union
Supply Capacity: 30 pcs / week
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
JCYC
Certification
CE
Model Number
DY
Product:
1 Ton Stage Electric Hoist
Warranty:
1 Year
Usage:
Stage Show
Power Source:
Electric
Sling Type:
Chain
Lift Speed:
4m/min
Maximum Lifting Weight:
2t
Maximum Lifting Height:
30m
Highlight:

horizontal lifting clamp

,

steel lifting clamps

Product Description
1 Ton Electric Chain Hoists for Stage with Double Brake Entertainment
The Stage Electric Chain Hoist is engineered specifically for stage performances, events, and entertainment applications. It features an intelligent numerical control system for precise positioning and smooth operation, combined with high-strength manganese steel chain for superior load capacity and durability. The aviation-grade aluminum housing ensures a lightweight yet robust structure, facilitating easy installation and handling.
Key Features
  • Independent dual electromagnetic brakes for maximum safety
  • Waterproof lighting system for stage applications
  • Intelligent numerical control for precise positioning
  • High-strength manganese steel chain
  • Aviation-grade aluminum alloy housing
  • Low noise operation (≤ 55 dB)
  • Variable speed lifting (0-7 m/min)
  • IP55 protection class
Technical Specifications
Capacity 1000 kg
Product Dimensions 727 × 252 × 185 mm
Net Weight 44 kg
Housing Material Aviation-grade aluminum alloy
Chain Length 20 meters
Chain Brand Japan FEC imported chain
Chain Specification 7.1 × 21 mm
Safety Factor (Breaking Strength) 10×
Chain Falls 1
Brake System Independent dual electromagnetic brakes
Noise Level ≤ 55 dB
Lifting Speed 0-7 m/min (variable speed)
Protection Class IP55
Motor Type Servo drive motor
Standard Power Supply 220V / 3 Phase / 50Hz
Duty Cycle 60% JC
Motor Power 3 kW
Motor Speed 0-2800 rpm
Upper & Lower Travel Limits 4 electronic limit switches
Repeat Positioning Accuracy ±0.1 mm
Safety Standard Complies with C1 safety level
Product Images
1 Ton Electric Chain Hoists for stage With double brake Entertainment 0
1 Ton Electric Chain Hoists for stage With double brake Entertainment 1
1 Ton Electric Chain Hoists for stage With double brake Entertainment 2
1 Ton Electric Chain Hoists for stage With double brake Entertainment 3
1 Ton Electric Chain Hoists for stage With double brake Entertainment 4
1 Ton Electric Chain Hoists for stage With double brake Entertainment 5
Manufacturer Profile
1 Ton Electric Chain Hoists for stage With double brake Entertainment 6
Industry Exhibitions
1 Ton Electric Chain Hoists for stage With double brake Entertainment 7
1 Ton Electric Chain Hoists for stage With double brake Entertainment 8
