1000kg Stage Chain Hoist Flight Case Package With 4-channel Control Box

MOQ: 2 pcs
Price: Negotiable
Standard Packaging: Wooden or flight case
Delivery Period: 5 working days
Payment Method: T/T
Supply Capacity: 50 pcs / week
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
JCYC
Certification
CE
Model Number
HHD
Product Name:
Stage Chain Hoist
Warranty:
2 Year
Power Supply:
3P 220V 50/60Hz
Motor Power:
750W
Standard:
CE
Noiselevel:
< 75 DB
Weight:
50 Kg
Liftingcapacity:
0.5 Ton To 2 Tons
Lift Chain:
G80
Usage:
Construction Hoist
Working Degree:
-40 - 40 Degree
Ins Class:
F
Lifting Chain:
G80
Key Words:
Electric Chain Hoist, Electric Trolley
Highlight:

horizontal lifting clamp

,

steel lifting clamps

Product Description
1000kg Stage Chain Hoist Flight Case Package With 4-channel Control Box
Professional Stage Chain Hoist

This product is specially designed for professional stage lighting, sound systems, performances, and other high-altitude installation applications, such as suspended inverted installations and elevated construction operations.

  • Compact and lightweight design for easy installation and operation
  • Single-phase power supply provides convenient access, saving installation time and improving work efficiency
  • Reliable braking system with safety protection that ensures secure operation and extended service life
  • Made of Grade 80 alloy steel chain with 3-fold safety factor for high strength and excellent durability
  • Professional chain guide wheel system ensures smooth chain movement, prevents jamming and twisting
  • Nylon chain guide has service life more than five times longer than conventional designs
  • Separate connector-type synchronous controller available for single or multiple hoists operating synchronously
  • Optional 4-channel, 8-channel, 12-channel, and multi-channel control boxes for synchronized control
  • Optional flight case (air box) package for professional protection and convenient transportation
Product Specifications
1000kg Stage Chain Hoist technical specifications diagram
Item Specification
Rated Load Capacity 1000 kg
Product Dimensions 306 × 235 × 235 mm
Net Weight 30 kg
Material Alloy Steel
Chain Length Optional
Chain Color Galvanized White (Black Optional)
Load Chain Specification 8 × 24 mm
Chain Safety Factor 8 Times Breaking Load
Chain Weight 1.33 kg/m
Number of Chain Falls 1 Fall
Chain Bag Included
Brake System Single Brake
Protection Class IP54
Motor Model YHPE750-4
Standard Power Supply Three-phase 380V / 50Hz
Optional Voltage 110V-440V (Customized)
Duty Cycle 40% ED (JC)
Motor Insulation Class Class F
Motor Power 750 W
Motor Speed 1380 rpm
Overload Protection Mechanical Overload Protection Device
Limit Switch Electronic Limit Switch
Lifting Speed 4 m/min
Noise Level ≤60 dB
Packing Size (Wooden Case) 540 × 390 × 285 mm
Packing Size with Flight Case 610 × 450 × 560 mm
Warranty 2 Years
