Double Girder Electric Wire Rope Hoist Overhead Crane Hoist 32t Lifting

Double Girder Electric Wire Rope Hoist Overhead Crane Hoist 32t Lifting
Double Girder Electric Wire Rope Hoist Overhead Crane Hoist 32t Lifting Double Girder Electric Wire Rope Hoist Overhead Crane Hoist 32t Lifting

Large Image :  Double Girder Electric Wire Rope Hoist Overhead Crane Hoist 32t Lifting

Product Details:
Place of Origin: China
Brand Name: JCYC/OEM
Certification: CE & ISO
Model Number: JCYC-SHSL-A/B
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export plywood cases or at your request
Delivery Time: 15 to 20 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month
Detailed Product Description
Product Name: European Electric Wire Rope Hoist Motor: European ABM/SEW Motor
Contactor: Schneider Brand Application: Double Girder Overhead Crane
Lifting Capacity: 3.2t - 80t Lifting Height: 6m/9m/12m/15m/18m
Protection Class: IP55 Color: As Per Request
High Light:

IP55 Electric Wire Rope Hoist

,

32t Lifting Overhead Crane Hois

,

6m Lifting Electric Wire Rope Hoist

European Model Double Girder Overhead Crane Hoist 32t Lifting Equipment





Brief overview



Compared with the traditional Foot Mounted Hoist, the structure of European type hoist is more reasonable and the technology is more advanced. So this type of hoists is more and more widely used and will be the development tendency. In order to stand out in the group of electric wire rope hoist suppliers, we constantly improve the technology to produce high level hoist to be aligned with the world.



Advantages



1. Modular design, can be flexibly combined into different lifting tonnage lifting speed and work hierarchy

2. European standard hoist trolley, It employs motor of hoisting mechanism and reducer imported from Germany.

3. The integrated and compact design of hoisting motor, reducer, reel and limit switch saves space for the user.

4. Standardization, user-friendly design in improving operating performance while greatly reducing maintenance costs

5. Smooth design helical gear surface hardening and grinding process, drive more efficient



Technical parameters



Capacity ton Lifting height m Lifting speed m/min Lifting motor kw Traveling speed m/min Traveling motor kw Lifting System FEM/ISO Traveling System
FEM/ISO
Trolley Rail Gauge mm
3.2t 6/9/12/15/18 5/0.8 3.2/0.42 5/20 0.25x2 2M M5 2M M5 1000-1700
5t 6/9/12/15/18 5/0.8 6.1/1 5/20 0.37x2 2M M5 2M M5 1000-1700
6.3t 6/9/12/15/18 5/0.8 6.1/1 5/20 0.37x2 2M M5 2M M5 1000-1700
8t 6/9/12/15/18 5/0.8 9.5/1.5 5/20 0.37x2 2M M5 2M M5 1000-2000
10t 6/9/12/15/18 5/0.8 9.5/1.5 5/20 0.37x2 2M M5 2M M5 1000-2000
12.5t 6/9/12/15/18 5/0.8 12.5/2 5/20 0.55x2 1AM M4 2M M5 1000-2000
16t 6/9/12/15/18 4/0.6 16/2.6 5/20 0.55x2 2M M5 2M M5 1400-2400
20t 6/9/12/15/18 4/0.6 16/2.6 5/20 0.55x2 1Am M4 2M M5 1400-2400
25t 6/9/12/15/18 3.3/0.8 20/5 5/20 0.75x2 3M M6 2M M5 1700-3100
32t 6/9/12/15/18 3.3/0.8 20/5 5/20 1.1x2 2M M5 2M M5 1700-3100
40t 6/9/12/15/18 0-4 38 5/20 1.5x2 1Am M4 2M M5 1700-3100
50t 6/9/12/15/18 0-3 38 5/20 1.5x2 2M M5 2M M5 1700-3100
50t 6/9/12/15/18 0-3 38 5/20 1.5x2 2M M5 2M M5 2000-4200


Product show

Double Girder Electric Wire Rope Hoist Overhead Crane Hoist 32t Lifting 0

Double Girder Electric Wire Rope Hoist Overhead Crane Hoist 32t Lifting 1Double Girder Electric Wire Rope Hoist Overhead Crane Hoist 32t Lifting 2Double Girder Electric Wire Rope Hoist Overhead Crane Hoist 32t Lifting 3
